5-TRANSPORTOPERATIONS
Loadingthemachineonarearloadingtypetrailer(withoutfrontequipmentinstalled)
WARNING
Tip-overhazard!
ThecounterweightMUSTberemovedbeforetransportingthemachinewithoutanattachment.Con-
sultyoudealer.
Failuretocomplycouldresultindeathorseriousinjury.
W0260A
WARNING
Pressurizedsystem!
Beforeremovingtheattachmentfromthemachine,makesuretheairpressureandhydraulicoilpres-
sureareatzero.
Failuretocomplycouldresultindeathorseriousinjury.
W0284A
Ifthemachinehastobetransportedwithoutthecompletefrontequipment(boomandarm),thecounterweightshould
beremovedfromthebasemachine.Loadingthebasemachineonthetrailerwiththecounterweightinstalledaffects
thestabilityofthebasemachineitself,anddenitelycompromisesitsclimbingability.
NOTICE:Theuseofliftingsystemsisnecessaryforremovalandinstallationofthemachinefrontattachmentandof
thecounterweight.RefertoyourCASECONSTRUCTIONdealerforproperremovalandinstallationprocedure.
CX130C–CX130CLC
SelecttheHworkmode.
Alignthemachinetothetrailer,soasthetravelmotors
facethetrailerramps.
NOTICE:Startingfromthisposition,thetravelcontrol
leversmustbepulledbackwardtomoveontheramps
andonthetrailerbed.Conrmthetravelcontroldirec-
tionsbeforestartmovingontotheramps.
Slowlyclimbthetrailerramps.Slowlytravelonthetrailer
bedtoreachtherestingposition.
SMIL13CEX2721AB10
Slowlyturntheupperstructure180°.
SMIL20CEX0029AB11
5-5
