6-MAINTENANCE

5.Loosenthecoolantdrainplugontherightsideofthe

engineblock.Draincoolantinsidetheengine.

K272V1-0083

6.IfenginehasEGRsystem,loosentheairbleedplug(1)

ontheEGRcooler.

7.Closethecoolantdraincockoftheradiator.

NOTICE:Thecoolantdraincockoftheradiatorshouldbe

tightenedbyhand.Itmaybedamagedifbeingtightened

withtoolssuchaspliers.

8.Closethecoolantdrainplugontheengineblock.

NOTICE:theengineshallneverbestartedwithnowater

intheradiator.Thiscausestheenginetoseizeup.

NOTICE:thedrainedcoolantshallbedisposedaccording

tothelocalRegulationsforcoolantuids.

SMIL17CEX0170AA4

6-64
