9-ACCESSORIES
Settingrangesforauxiliaryhigh-owhydrauliccircuit
Themaximumowrateoftheauxiliaryhigh-owhydrauliccircuitcanbesetbymonitor.Thesettingrangesarerelated
tothecircuittypeinstalledonthemachine.
Ifsingle-actingcircuitisinstalled,themaximumowratecanbeselectedwithinthestepsintheleftcolumnofthe
tablebelow.
Ifmultifunctioncircuitisinstalled,thesettingrangesarerelatedtothecircuitmode.IntheSingle-actingmode,the
maximumowratecanbeselectedwithinthestepsintheleftcolumnofthetablebelow.IntheDouble-actingmode,
themaximumowratecanbeselectedwithinthestepseitherintheleftcolumnorintherightcolumnofthetable
below.
NOTE:allthevaluesformaximumowratearerelatedtotheSPworkmode.Iftheauxiliaryhigh-owhydrauliccircuit
isusedwithadifferentworkmodetheactualowwillbelower.
1pumpow2pumpsow
35L/min(9.25USgpm)164L/min(43.32USgpm)
39L/min(10.30USgpm)168L/min(44.38USgpm)
53L/min(14.00USgpm)182L/min(48.08USgpm)
64L/min(16.91USgpm)193L/min(50.99USgpm)
75L/min(19.81USgpm)204L/min(53.89USgpm)
87L/min(22.98USgpm)216L/min(57.06USgpm)
100L/min(26.42USgpm)229L/min(60.50USgpm)
111L/min(29.32USgpm)240L/min(63.40USgpm)
119L/min(31.44USgpm)248L/min(65.51USgpm)
129L/min(34.08USgpm)258L/min(68.16USgpm)
NOTE:Fiveowratevaluescanbesetandstoredforusageofsingle-actinghydraulicattachments.Fiveowrate
valuescanbesetandstoredforusageofdouble-actinghydraulicattachments.
FortheSingle-actingcircuittheworkingpressureshallbesetmanuallybytheportreliefvalveontherelevantsection
ofthecontrolvalve.
FortheMulti-functioncircuittheworkingpressureshallbesetmanuallybythereliefvalvelocatedbehindtheboom
foot.
9-7
