9-ACCESSORIES
Auxiliarylow-owhydrauliccircuit
Themachinecanbeequippedwithanadditionallow-owauxiliaryhydrauliccircuittooperateattachmentsfeaturing
secondaryhydraulicactuationforpositioning,suchasrotatinggrabsortiltablebuckets.
NOTE:themaximumowrateoftheauxiliarylow-owhydrauliccircuitusingtheSPworkmodeis55L/min(14.5US
gpm).Themaximumworkingpressureoftheauxiliarylow-owhydrauliccircuitis20.6MPa(2988psi).
NOTE:anadditionaldrainageline(D)islocatedontheleftsideofthearm.Thedrainageline(D)isintendedtoallow
externaldrainagefromanhydraulicmotor.
NOTICE:alwayskeepeachconnectinghoseonthesamesideofthearm.Nevercross-overtheconnectinghoses
betweenthetwosidesofthearm.
Usetheproportionalswitchlocatedontheleft-handcon-
trollevertooperatethegrabrotationorthebuckettiltwith
avariablepower.
Makesurethatthecontrolpatternofthepositioningactu-
ationisasintended.Slideupanddowntheproportional
switchandconrmthecontroldirections(e.g.left/right).
NOTICE:ifcontroldirectionsforthepositioningactuation
arenotasintended,checkforanalternativesetupofthe
hydraulicconnectionsbetweentheattachmentandthe
machine.
NOTICE:ifnotusinganyhydraulicattachment,donot
operatecontrolsforauxiliaryhydrauliccircuits.
