3-CONTROLSANDINSTRUMENTS
1.Enginecoolanttemperaturegauge.
Displaysthetemperatureoftheenginecoolant.The
lowerzoneindicatesthattheenginecoolanttemper-
atureislow.Whenthetemperaturegaugedisplay
reachestheupperzone,analarmsoundsandthe
OVERHEATmessageisdisplayed.Lowertheen-
ginespeed.Ifthetemperaturedoesnotgodown,
stoptheengine,removethestarterkey,andinvesti-
gatethecause.
2.Hydraulicoiltemperaturegauge
Displaysthetemperatureofthehydraulicoil.The
lowerzoneindicatesthatthehydraulicoiltemper-
atureislow.Whenthetemperaturegaugedisplay
reachestheupperzone,analarmsoundsandthe
OVERHEATmessageisdisplayed.Lowertheen-
ginespeed.Ifthetemperaturedoesnotgodown,
stoptheengine,removethestarterkey,andinvesti-
gatethecause.
3.Fuelgauge
Displaystheremainingamountoffuelbythenumber
oflitsegments.Whenallarelit,itindicatesthatthe
fueltankisfull.Whenonly1islit,analarmsounds
andtheLOWFUELmessageisdisplayed.
NOTE:Itisnotnecessarytowaituntilthefueltank
isemptybeforellingwithfuel.Ifthetankbecomes
empty,airbleedingofthefuelsystemisrequired.
4.Workmodeicon.
TheAworkmodeisselected.
TheHworkmodeisselected.
TheSPworkmodeisselected.
5.Travelmodeicon.
Theslowspeedtravelmodeisselected.
Thefastspeedtravelmodeisselected.
6.Workinglightsicon.
Theworkinglightsareon.
7.Engineautoidleiconandautostopicon.
Engineautoidleisset.
Engineautostopisset.
Autoidleandautostopareboth
set.
8.Anti-thefticon.
Theanti-theftprotectionfunctionissetup.
9.Attachmentselectionicon.
10.Dateandtime.
11.Auxiliaryhydraulicssetting.Whenanoptioncircuit
ismounted,theselectedowandpressurearedis-
played.
MUC8LU-043Z4
Largetemporaryicon.
Alargeiconappearstemporaryinthemiddleofthe
displayinordertoindicateaspecicoperatingcon-
dition
•Wiperspeed
1stspeed
2ndspeed
3-31
