3-CONTROLSANDINSTRUMENTS
Stop
•Enginepreheating
12.Ecogauge
Thenumberofindicatorsonthisgaugeincreases
whentheoperatingstateisenergy-savingoperation.
Ifhigh-loadoperationsareperformed,thenumberof
gaugeindicatorsdecreases.
Thestateofenergy-savingoperationsisindicated.
•Nomechanicalabnormalitieswilloccurevenifthe
numberofgaugeindicatorsdecreases.However,to
helpconservetheenvironment,trytoperformen-
ergy-savingoperationswithinthegreenrange,so
longasdoingsodoesnothinderwork.
Keypointsforenergy-savingoperations
•TrytouseHmodeorAmodeinsteadofSPmode.
•Avoidsharpleveroperations.
•Avoidhighloadandreliefoperations.
•Useautoidleandone-touchidle.
Also,useidlestoptostopunnecessaryidling.
AskyourCASECONSTRUCTIONDealerabouthow
toturntheecogaugedisplay“On”and“Off”.
13.Autopressureboosticon
Displayedwhenthemaximumoutput
stateisenteredautomaticallyforthe
attachment.
14.Radiomuteicon.
Radioismuted.
15.Hourmeterandtripmeter.
Thehourmeterindicatesthetotalengineoperating
hoursinunitsof0.1h6min.Thetripmeterallows
tosetapartialoperatinghourcounter,whichcanbe
resetto0hatanytime.Thehoursareindicatedin
unitsof0.1h6min.
16.FueleconomydisplayandDTC(DiagnosticTrouble
Code)display
Theinstantaneoustime/fuelconsumption“gph”is
displayed.
TheDTC(DiagnosticTroubleCode)isdisplayed
here.
17.Messages
MUC8LU-042Z5
Themessagesonthebottomofthedisplayarein-
tendedtoprovidesignicantinformationrelatedto
themachineoperation.Amessagecombinesan
iconandatext.Somemessagesareaccompanied
byanalarmastheyaredisplayed.Amessagecan
haveared,orangeorgreenbackgrounddepending
uponthetypeofmessage,accordingtoitslevelof
urgencyandimportance.
Analarmalsosoundswhensomeofthesemessages
aredisplayed.
NOTICE:Ifamessageisdisplayed,performaction
accordingtothemessage.
NOTICE:Ifthemessageisstilldisplayedafteraction,
consultyourCASECONSTRUCTIONDealer.
NOTE:Thelanguageofthedisplayedmessagescan
bechanged,consultyourCASECONSTRUCTION
Dealer.
•
LOWOILPRESSURE
Indicatesthattheengineoillevelislow.An
alarmsounds.Stoptheengineandremove
thestarterkey,andtheninspecttheoillevel.
NOTE:Ifthemeasuresabovearenotperformedim-
mediatelywhenthismessageisdisplayed,theengine
stopsautomatically.
•
OVERHEAT
Indicatesthattheenginecoolant
temperatureishigh.Analarmsounds.
Lowertheenginespeed.Ifthetemperature
doesnotgodown,stoptheengineand
removethestarterkey.Waitforthe
temperatureofthecoolingsystemtogo
down,andtheninspectthecoolantlevel
insidethereservoirtankandradiator.Check
theradiatorandoilcooler.
•
BOOSTTEMPHIGH
