Appendix (Peripheral configuration)
Select these options:
1. Interface selection:
SNI RS-232C interface selection
2. Baud rate:
Baud rate = 9600 bps
3. Data format settings:
Parity = Odd
Stop bits = One
Data bits = Eight bits
4. Software control:
Hardware control = Enable CTS/RTS flow control
Software control = Disable Xon/Xoff
5. RS-232C ACK/NAK options:
ACK/NAK enable = Disable ACK/NAK
6. Setting symbology specific label identifiers:
Transmit label I.D. as prefix
“SNI RS232C” default value:
1. General features:
Audible signal = Enable
Power-up beeping = Enable
Beeper volume = Low
Beeper duration = 100ms
When to beep = Beep/LED after decode
Low power mode = Disable
Debug mode = Disable
Auto sense stand mode = Disable
2. RS-232 I/F settings:
RS-232 I/F = N/A
SNI RS-232 I/F = Enable
Baud rate = 9600
Parity = Odd
Stop bit = 1
Data bit = 8
Hardware control = Use CTS/RTS flow control
Software control = Disable = Xon/Xoff
Intercharacter delay = 0
Keyboard wedge I/F settings:
KBD wedge I/F type = N/A
External keyboard/No keyboard = N/A
Send control characters = N/A
Intercharacter delay = N/A
3. Label transmit format config items:
Prefix = Disable
Suffix = Global D00
Label I.D. control = Transmit as prefix
UPC-A label I.D. = 4100
4. Symbology:
UPC/EAN = Enable
5. UPC/EAN options:
UPC-A to EAN-13 expansion = Expand
UPC-E to UPC-A expansion = Don’t expand
EAN-8 to EAN-13 expansion = Don’t expand
UPC-E to EAN-13 expansion = Don’t expand
Quick scan 6000
