13
Ready
※You can connect the common AC adaptor 01 (option) to the W51CA directly to
charge the battery pack.
Check the shape of the connector ends
to ensure they are aligned correctly
(shown above) when connecting.
Connect the common AC adaptor 01 (option) to the
desktop holder.
Check the shape of the connectors to ensure they are aligned correctly before
you connect.
Tr ying to force a connection may damage the connectors.
Insert the W51CA into the desktop holder.
Fold out the power plug of the common AC adaptor 01
(option), and then plug it into a 100V AC power outlet.
This will cause the W51CA LED indicator to light red, and (charging battery
icon) to display.
When charging is completed, the battery level icon will show
and the LED
indicator will go out.
When charging the battery with your W51CA in Viewfinder position, check the
charging battery icon shown on the screen. If you set “Func in Charge” to
“MEDIA STAND,” the screen keeps illuminating with the normal brightness.
To remove the W51CA from the desktop holder, holding the holder by hand
and remove W51CA.
