CCV OPM-C60 - Page 59

OPM-C60/OPP-C60
System Manual
PA72P002_en
Edition: 40
Page 59 - 68
Product specific instructions
Confidential
© CCV GmbH - It is not allowed to duplicate or distribute this document without our agreement.
Station Cards
PIN-check is supported for the following station cards.
- Proeda station card
- Hectronic station card
- Huth station card
- Scheidt&Bachmann
- Wayne-Dresser
- Ratio
- Task
- Tokheim
- BICA
With the command 06 E3 it’s possible, with aid of Bitmap D0 (Algorithmkey) and Bitmap D3
(Key slot), to use the following combinations (all values are decimal, track positions will be
counted with start symbol = 1):
Key slot
(BMP D3)
PIN-Data (BMP D1)
Algorithm
key (BMP D0)
Card
1
8 Byte binary
0
Hectronic
2
8 Byte binary
0
Proeda
3
8 Byte BCD: Track 2 Pos 3-17, number 0, 2
Byte BCD: Track 2 Pos 27-30
2
UTA
4
8 Byte BCD: Track 2 Pos 3-18, 2 Byte BCD:
Track 2 Pos 30-33
70
DKV Selection Card
5
8 Byte BCD: Track 2 Pos 5-20, 2 Byte BCD:
Track 2 Pos 27-30
2
BFT
6
8 Byte binary
0
Huth
7
8 Byte BCD: Track 2 Pos 2-7, 11-19, die Ziffer
0, 2 Byte BCD: Track 2 Pos 31-34
2
LOMO
8
8 Byte BCD: Track 2 Pos 3-18, 2 Byte 0
70
BayWa-Card
9
8 Byte BCD: Track 2 Pos 3-18, 2 Byte BCD:
Track 2 Pos 28-31
70
WEAT-Card
10
8 Byte BCD: Track 2 Pos 3-18, 2 Byte BCD:
Track 2 Pos 27-30
2
Westfalen-Card
11
8 Byte BCD: Track 2 Pos 3-13,
Track 2 Pos 32 = 1 or 2: Track 2 Pos 15-
18,
Track 2 Pos 32 = 3: Track 2 Pos 5-8,
Track 2 Pos 32 = 4: 4-digit drivers code,
number 0, 2 Byte BCD: Track 2 Pos 28-31
2
Routex
12
8 Byte binary, 2 Byte PIN-Offset BCD
2
Scheidt&Bachmann
Track 2
