112
5. Hold the muffler and then remove
the mounting bolts.
6. Slightly rotate the muffler and pull
it back to remove the muffler.
7. Press the connector latch and
disconnect the O2 sensor
harness connector.
8. Hold the front exhaust pipe and
remove the mounting nut on the
cylinder head.
To Next Page
