THE REAR DRIVESHAFT ASSEMBLY
Before install gear and bearing , please lubricate with 10W/40 oil
1.Press the bearing (2) into the shaft (1) thoroughly.
2.Install the gear (3) into shaft (1).
3.Tighten the bolt(5) with washer (4) on the shaft (1) , the tighten
torque 20Nm
4.Install the washer (6) which thickness shall be measured in advance
into shaft (1) , then press the bearing (7) into shaft (1) , finally intsall
the O ring (8)
46050025O-RING8.
DGB6305BEARING7.
46050009-19WASHER6.
BFH080251094BOLT5.
46050007WASHER4.
46050023GEAR 3.
DGB6205BEARING2.
46058001DRIVE SHAFT ASSY.1.
PART NO.PART NAMENO.
