cectek Gladiator - Rear Lhs & Rhs A-Arm Assy. Removal

129
7.The nut of rear LHS shock upper
mounting should be put toward
rear of ATV.
REAR LHS & RHS A-ARM ASSY.
REMOVAL
1.Remove the knuckle upper
mounting bolt and nut.
2.When install torque 40Nm.
3.Remove the knuckle lower
mounting bolt and nut.
4.When install torque 40Nm.
5.Remove the A-arm upper
mounting bolt and nut.
6.When install torque 40Nm.
Nut
RF
