1
30
7.Remove the rear
upper
A-arm
Assy
.
8.Remove the lower
A-arm front
mounting bolt and nut.
9.When inst
all torque 40Nm.
10.Remove the rear lower
A-arm
af
ter mounting bolt and nut.
1
1.When install torque 40Nm.
12.Remove the rear lower
A-arm
assy
.
136
138
