139
2.Push the caliper bracket to retract
the piston.
3.Remove the brake pads.
FOOT BRAKE PADDLE REMOVAL
1.Remove the cutter pin on the foot
brake cylinder link pin.
2.Remove the foot brake cylinder
link pin.
(1)
(2)
