1.Install pin (2) into balancer
shaft (1)
2.Install gear-oil pump driver (3)
into balancer , reference to
figure A
3.Clip the E-ring (4) check the
retain E-ring install into the
groove of balancer shaft
THE BALANCER ASSEMBLY
40128004BALANCER SHAFT ASSY.4.
40130083PIN3.
40150030GEAR (37T)2.
RES009RETAIN E-RING1.
PART NO.PART NAMENO.
47
