THE CYLINDER HEAD ASSEMBLY (1/3)
40050140VALVE SPRING WASHER5.
SC050121291HEXAGON SOCKET SCREW4.
40070031SEALING BALL3.
40056002VALVE STEM SEAL2.
40058011CYLINDER HEAD ASSY.1.
PART NO.PART NAMENO.
Please clean up correlative parts and lubricate with 10W/40 oil
1.Knock the 2 balls (2) into cylinder head (1)
2.Paste the screw (4) with LT272 , tighten to cylinder head with 5Nm
3.Install the washer (5) on the valve spring seat
4.knock valve stem seal (6) into valve guide , keep distance between
the bottom of seal and the top of cylinder head within 12.7±0.5 mm
2
53
