THE CYLINDER HEAD ASSEMBLY (2/3)
40056003VCOTTER5.
40050136SRIING CAP4.
40050135SPRING3.
40050134VALVE (EXHAUST)2.
40050133VALVE (INTAKE)1.
PART NO.PART NAMENO.
Please clean up correlative parts and lubricate with 10W/40 oil
1.Install valve spring (3) x4 on the valve spring washer
2.Install cotter (5) x2 on the spring cap (4) (4pcs)
3.Install assembled spring cap (3) on the spring , with jig press it into
the valve stems until a clear "clik" sound was heard
4.check the cap is firmly installed on the stem with jig
54
