CECTEK 500cc EFI ENGINE
ASSEMBLY
CAUTION：
Only trained and certificated technician can disassembly the
CECTEK RSGA 500 EFI ENGINE. Improper disassembly may damage
the engine. CECTEK can not provide the warranty to the engine
which has not been properly disassembled and assembled by trained
and certificated technician.
THE PISTON AND CONNECTION ROD ASSEMBLY
1.Before assembly , must confirm
if the piston (4,5) is matching
the category of liner
2.A category piston only can be
installed on A category liner
3.A category piston only can be
installed on B category liner
40096015PISTON RING OIL CONTROL8.
40096014PISTON RING SECOND7.
40096013PISTON RING TOP6.
40096012PISTON-B5.
40096011PISTON-A4.
40090027CLIP3.
40090024PISTON PIN2.
40098013CONROD ASSY.1.
PART NO.PART NAMENO.
4.Make sure the liner size mark
of the cylinder block
