Remove the spin nose and
washer
Loosen the front driveshaft yoke
bolts , then remove the yoke
Loosen the front driveshaft seal
cover bolt*3 , then remove the
cover
THE DRIVESHAFT DISMANTLE
The yoke
The seal cover
35
