128
REAR LHS & RHS SHOCK
ABSORBER REMOVAL
1.Hang the A-arm by rope.
2.Remove the shock absorber upper
mounting bolt and nut.
3.When install torque 40Nm.
4.Remove the shock absorber lower
mounting bolt and nut.
5.When install torque 40Nm.
6.The nut of rear RHS shock upper
mounting should be put toward
front of ATV.
Nut
F
R
