85
6. Remove the front upper latch
screw.
7. Pull the cover backward
(direction 1).
8. Slightly lift the cover up and pull
the cover upward (direction 2)
for removing the cover.
FRONT BUMPER COVER
REMOVAL
Reversely perform the below
process to install.
1. Remove the upper two screws
on the cover.
2. When install torque 10Nm
(1)
(2)
