5. Pull the upper saddle cover
backward and the lift it up to
remove the cover.
SIDE SADDLE COVERS REMOVAL
(LHS & RHS are in same process)
1. Must remove the upper saddle
cover before removing side
saddle cover.
2. Remove the frame fastening
screw.
3. When install torque 10Nm.
4. Remove the rear latch screw.
5. Remove the front loser latch
screw.
