cectek Gladiator - Seat Removal

81
SEAT REMOVAL
1. Turn the steering handle to the
dead left position.
2. Push the key and turn it to
“SEAT OPEN” position.
3. Then you will hear the latch
release sound “Click”.
4. Lift the seat up and draw the
seat backward to remove the
seat.
INSTRUMENT COVER REMOVAL
1. Remove the 2 screws on the
upper instrument covers.
