87
MAINTENANCE ACCESS PANEL
REMOVAL
Reversely perform the below
process to install.
1. Insert your two fingers into the
latch hole. Press the latch to
release the panel.
2. Slide the panel out under the
front rack.
3. Note: for ATV Quadrift 500 EFI,
There is not rack above the
maintenance access panel. You
can direct lift up the panel.
KEY POSITION COVER REMOVAL Reversely perform the below
process to install.
1. Remove the key out.
To Next Page
