Screw the Belt Removal Tool to
end to open the driven pulley ,
then removal the belt
The belt
※Reinstall , the installer must
can read the printed word on
the belt
Loosen the driven pulley bolt ,
then remove the driven pulley
CVT BELT DISMANTLE
CVT DRIVEN PULLEY DISMANTLE
The Driven pulley
22
