12.1mm

THE WATER PUMP ASSEMBLY

Please clean up correlative parts and keep dry

1.After install machianicla seal (2) on water pump shaft (3) and check

the shaft have 12.1mm between macanicla seal and water pump

shaft

40070064CAP8.

40130063GEAR (35T)7.

40130083PIN6.

40130077WASHER5.

40130071PROPELLER4.

40130075SHAFT3.

40136011MACHANICLA SEAL2.

40010053ACCESSORY COVER1.

PART NO.PART NAMENO.

RCS012RETAIN C-RING9.
