11
7
2. Remove the cutter pin on the ball
joint mounting nut.
3. When inst
all torque 30Nm.
4. Remove the ball joint mounting
nut.
5. When inst
all torque 30Nm.
6. Remove the nut and washer
.
7. Remove the ball joint form
knuckle by ball joint puller
.
123
