121
4.Remove the hub nut and washer.
5.Use the hub CV joint bolt as the
support to pull the hub out with
the brake disk.
FRONT LHS & RHS A-ARM ASSY.
REMOVAL
1.Remove the cutter pin on lower
A-arm knuckle ball joint bolt.
2.Remove the nuts and washers.
3.When install torque 30Nm.
To Next Page
