Injector
Part Introduction
Identification Code: 28140652
Injector holes:
4ea
Circuit Diagram :
Measurement
Resistance: 12.0±0.6Ω
ECU
Injector
Pin 28
MPR
Main Power Relay
-
+
Identification Code:
28140652
ECU Pin 28: -
MPR: +
12
