Install rear drive shaft to cylinder
block , then push it to positi
on
Install main shaft and push the
needle bearing to position
Lubricate oil release valve and
install valve
、
spring guide into
cylinder block
Then screw the b
olt
※
Torque 10Nm
5
9
65
