Install the spark plug
※
Torque 10~12Nm
Lubricate the spin n
ose and ,
then install into cyli
nder block
Install the fly wheel assy. and
ALT rotor , then screw
the nut
※
Torque 200Nm
Install the cylinder head cover ,
then screw the bolt
s
※
Torque 10Nm
