CenterVue
DRS Operating Manual
Pg. 50 of 57
21. TECHNICAL SPECIFICATIONS
Class and type of applied part
I, B (according to IEC 60601-1).
IP classification
IPX0 (according to IEC 60529, related to the degree of protection provided by the enclosure with
respect to harmful penetration of particulate matter or water).
Retinal Imaging
 Field of view: 45° x 40°
 Non-mydriatic operation (3.8 mm minimum pupil size)
 Fixation target: internal LEDs
 Operating distance: 37 mm.
 Sensor size: 5 MPixel (2592 x 1944)
 Resolution: 48 pixels/deg
 Resolution on retina: 15 µm
 Pixel pitch on retina: 6 µm
Other features:
 Patient presence sensor
 Motorized chin-rest
 Automatic alignment
 Auto-focus (adjustment range: from -15D to +15D)
 Auto-flash level adjustment
 Touch-screen color display
 Embedded PC
 Ethernet connectivity
Dimensions:
 Weight: 19 Kg (42 lbs.)
 Size: 55 × 55 × 33 cm (22 × 22 × 13 in)
Accessories:
 Power cord;
 Spare fuses;
 Operating Manual;
 Dust cover;
 Microfiber cleaning sheet for touch screen;
 Front lens photographic cleaning tissue, pack of single-use sheets;
 Silicone forehead rest;
 Hand blower;
 Glasses with adjustable prisms;
 USB 2.0 extension cord.
Power requirements:
 Voltage: 100-240 VAC, 50-60 Hz, fuse 3.15 A (T type)
 Power consumption: 100 VA
