CENTRALINE I/O MODULES – INSTALLATION & COMMISSIONING INSTRUCTIONS
EN1Z-0973GE51 R0119
54
Analog Output Feedback – nvoAoPosnFb[ ]
This value represents the current status of the analog output
including feedback related to manual override initiated from
the manual override.
This is typically used for monitoring purposes at a supervisory
station or for diagnostic purposes.
Valid Range
Table 53. Analog output feedback range
Value State Current analog output position
0.5 … 100 % 1
Analog output position due to
normal control by nviAoSwitch or
nviAoValuePct
0 % (OFF) 0
0 … 100 % -1
Manual override position via the
manual override panel
0xFF -1
Current position unknown or
synchronization active, analog
output not configured
Transmission
This variable is transmitted immediately when the
corresponding network input variable has changed more than
1 % or immediately as an answer to an
nviAoValuePct[ ] or nviAoSwitch[ ] update.
Default Service Type
The default service type is unacknowledged.
Analog Output Command – nviAoSwitch[ ]
This network variable is used to drive the analog output to
0 … 100 %.
It is typically bound to a L
ONWORKS control device issuing an
output level 0 … 100 %.
If both nviAoSwitch[ ] and nviAoValuePct[ ] receive valid
values, nviAoValuePct[ ] will have priority.
Default Value
Value = 0
State = –1
CLIOL823A Binary Input Module
One instance of the LONMARK open-loop sensor object has
been assigned per input of the CLIOL823A Binary Input
Module.
Each digital input object has its own configuration properties,
except for heartbeat configuration, which will be shared
among all objects.
nvoDiSwitch[x]
SNVT_switch
nvoDiCount[x]
SNVT_count
Configuration
Parameter
Value File
Open Loop Sensor Object
(LonMark Object Type 1)
|1
#1
nciDiConfig[x]
UCPT_DIConfig
nciSndHrtBt
SCPTmaxSendTime
Fig. 74. L
ONMARK digital input object
Transmission
These variables are transmitted immediately when its value
has been changed by a higher rate than the configured "send
on delta" (in the case of the totalizer, “send on delta” has a
default value of 5 counts).
These variables are also transmitted as a heartbeat output on
a regular basis as dictated by the max. send time
(nciSndHrtBt) (default = 0 = disabled) configuration variable.
Default Service Type
The default service type of these variables is
unacknowledged.
Fast Binary Input – nvoDiSwitch[ ]
This network variable output represents the logical state of a
fast binary input connected to the binary input terminals.
Valid Range
Table 54. Slow digital input values
Logical input state Value State
ON 100 % 1
OFF 0 % 0
Not configured 0 % -1
Default Value
The default value is set after power-up or reset and remains
until the module has measured a valid value.
Value = 0
State = -1
Totalizer Count – nvoDiCount[ ]
This network variable output indicates the total number of
transitions from 0 to 1 since the last reset due to power-up or
network reset.
