Page #7 background image
CENTRALINE I/O MODULES – INSTALLATION & COMMISSIONING INSTRUCTIONS
7 EN1Z-0973GE51 R0119
Interfaces and Bus Connections
The CentraLine I/O Modules can be connected to the
following devices and systems:
Panel Bus
For communication with up to 16 Panel Bus I/O modules
Polarity-insensitive
LONWORKS Bus
For communication with other LONWORKS Bus devices
within the building
FTT10, link power compatible
Polarity-insensitive
Technical Data
System Data
Table 7. System data
Operating voltage 24 VAC, ± 20 %, 21 … 30 VDC
Current requirement See Table 11.
Push-in terminals 1.5 mm
2
Screw-type terminals 1.5 mm
2
Overvoltage protection
The inputs and outputs of all
CentraLine analog and binary
I/O modules are protected
against short circuit, 24 VAC
+20%, and 40 VDC.
In the case of the relay outputs
of other CentraLine I/O
modules (i.e., relay output
modules, floating output
modules, and mixed I/O
modules), appropriate fusing
must be provided to ensure that
permissible load currents are
not exceeded.
Calculated lifetime of
weakest component under
typical operating
conditions
MTBF
13.7 years
System Constraints
Table 8. System constraints
Max. no. of I/O modules (any com-
bination) connected to controller
depends upon
controller type
Max. no. of I/O modules per row 10
Max. current (F1) 4 A
Max. current (F2) 12 A
Max. current (F3) 12 A
Max. row length 3 m
Max. distance between rows 40 m
Min. cross-section of GND (terminal
9) (protected by F2)
1.5 mm
2
Standards
Table 9. Standards
Protection class IP20
Product standard (EMC)
EN 60730-1
EN 60730-2-9
Testing electrical
components
IEC68
Certification CE
System transformer
The system transformer(s) must
be safety isolating transformers
according to IEC 61558-2-6.
In the U.S.A. and Canada, NEC
Class 2 transformers must be
used.
Low-Voltage Device
Safety Assessment
EN 60730-1
EN 60730-2-9
Operational Environment
Table 10. Operational environment
Ambient operating
temperature
0 … 50 °C (32 … 122 °F)
Ambient operating
humidity
5 … 93 % rel. humidity
(non-condensing)
Ambient storage
temperature
–20 … 70 °C (–4 … +158 °F)
Ambient storage
humidity
5 … 95 % rel. humidity
(non-condensing)
Vibration under
operation
0.024” double amplitude
(2 … 30 Hz),
0.6 g (30 … 300 Hz)
Dust, vibration According to EN60730-1
RFI, EMI Home environment
