Centurion D10 - D10 Turbo and D10 Parts Identification

page 12
www.CentSys.com
1.2. D10/ D10 Turbo parts identication
SECTION 1
PRODUCT IDENTIFICATION
1
2
3
4
10
11
12
13
6
7
8
5
9
FIGURE 2. D10/ D10 TURBO GATE MOTOR
1. D10/ D10 Turbo controller
2. Courtesy light fuse (3A F/B)
3. 2 x 12V 7.2Ah battery
4. Gate mounted origin Marker
5. Origin marker bracket
6. Origin sensor (clip under battery)
7. Lower cover
8. Foundation plate
9. Motor fuse (30A ATO)
10. D10/ D10 Turbo charger
11. Manual release handle
12. Lock cover
13. Encoder sensor (clips into support post)
