FEATURES AND FUNCTIONS SECTION 4
4.1.16. ChronoGuard Timer (a world rst)
ChronoGuard™ (a world rst) is a powerful multichannel timer feature which has been
added to the D5-Evo DOMESTIC, D10 and D10 Turbo controllers. A Real Time Clock
and Calendar (RTC) lets you set the following features to operate automatically or be
prevented from operating (time-barred) during any Time-period you choose:
• Trigger (TRG) (auto activation and time-bar
1
)
• Free-exit (FRX) (auto activation and time-bar
1
)
• Pedestrian opening (PED) (auto activation and time-bar
1
)
• Holiday Lockout (LCK) (auto activation and time-bar
1
)
• Closing Beam (IRBC) (auto activation only)
• Courtesy (Pillar) Light control (AUX) (auto activation and time-bar
1
)
• Courtesy (Pillar) Light relay (time-bar only
1
)
• Auxiliary output
2
(auto activation and time-bar)
A Time-period can be a once o event, or can be set to repeat on a weekly or annual
basis. The weekly repeat can be chosen to occur on every day of the week, weekdays
only, weekends only, or any specic day. The minimum duration of a time-period is one
minute – and you can set 100 dierent Time-periods. The “Tp” icon will appear on the
display to indicate that a time-period is active.
You can even set up dierent conditions by combining Time-periods as well as set up
exclusions (once o time periods when the auto activation or time-bar period must be
ignored) so your gate will automatically open at certain times on weekdays, but will know
not to open on a public holiday.
1. It is possible to time-bar the operation of the device physically wired to this feature and/or the same feature
controlled via the radio receiver.
2. Spare output, which via a relay board can drive a variety of external devices such as sprinkler system, fountain
etc.
FIGURE 33
4.1.16.1. Some examples of how
to use ChronoGuard:
Pillar / Courtesy Lights could be set
to switch on at 20:00 in combination
with Holiday Lockout Mode so your
driveway would be lit up and locked
down to keep you safe at night.
