We highly recommend that you use Infrared Safety Beams if you select
Condominium Mode in order to prevent the gate from closing on people,
pets or vehicles.
PIRAC (Passive Infrared Beam Autoclose) can be used with Condominium Mode.
4.1.2.4. PLC Mode
This highly specialised mode is suited to industrial applications where a separate
computer or programmable logic controller (PLC) is used to operate the gate. Three
separate inputs are used to open, stop or close the gate:
• Free-exit input (a trigger from the PLC will only open the gate)
• Holiday Lockout input (a trigger from the PLC will stop the gate)
• Trigger input (a trigger will only close the gate)
4.1.2.5. Deadman Control Mode
A variation of PLC Mode, Deadman Control Mode requires a pushbutton to be held in
order for the gate to be set in motion. If the button is released, the gate will immediately
stop.
Alternatively, an emergency stop pushbutton can be used to permanently hold the gate in
“Stop Mode”. Releasing the pushbutton will allow your gate to open or close.
If the open or closed triggers are held when the gate reaches the end of its cycle either
fully open or fully closed, the internal end-oftravel limit switch system will shut o the
motor and prevent further operation in the respective direction.
Autoclose and PIRAC (Beam Autoclose) cannot be used with PLC Mode
Autoclose and PIRAC (Beam Autoclose) cannot be used with Deadman Control
Mode
FEATURES AND FUNCTIONS
4.1.3. Automatic closing (Autoclose Mode)
The D5-Evo DOMESTIC and the D10 sliding gate operators have the facility to
automatically close the gate after it has opened. When enabling this feature, the time
that the gate stays open is by default fteen seconds (this time is adjustable
1
).
As described in the previous section Autoclose is selectable with Standard and Reversing
Modes and by default the function is o. However, Autoclose is automatically enabled in
Condominium Mode.
1. It is possible to adjust the delay before the gate closes in one second increments from zero seconds to four
minutes. The default time is ve seconds.
