D10/ D10 TURBO MANUAL OVERRIDE SECTION 3
FIGURE 8
FIGURE 9
FIGURE 7
Insert the split pin (supplied with the
mounting hardware kit), through the
hole in the gearbox as indicated
Make sure the split pin goes all the
way through as shown
Raise the handle and lock
Remove the key and fold back the
lock cover
Split pin
Split pin
