If the Courtesy Light (Page 20) is connected to the control card, it will ash
indicating that the gate will open a default distance of approximately one metre
(adjustable). The gate will close after a default time of ve seconds (adjustable).
The gate can be kept open by keeping a trigger on the input (keeping your key in
the keyswitch, for example) – once removed the gate will close after the default, but
adjustable, ve seconds.
The Pedestrian Opening Input is fully congurable and can be set to suit your needs.
You can adjust the pre-opening time delay; the amount that the gate opens; and the
pedestrian autoclose delay using your LCD controller.
If a Safety Beam is tted and the beam is broken while the gate is closing, the gate will
stop and open to the pedestrian position. The gate will remain open while the beam is
broken and the ve second (adjustable) Autoclose delay will only commence once the
beam has been cleared.
• For safety reasons it is recommended that all pedestrian keyswitches
and keypads are installed on the opposite end of the gate to where
the operator is installed
• It is possible to adjust the delay before the gate opens in one second
increments from zero to 65 seconds (one minute and ve seconds).
The default time is two seconds
• It is possible to adjust the width of the pedestrian opening from a minimum
of 50 millimetres to the full gate opening in ten millimetre increments.
The default opening is one metre
• It is possible to adjust the delay before the gate closes in one second
increments from zero to 65 seconds (one minute and ve seconds).
The default time is ve seconds
FEATURES AND FUNCTIONS SECTION 4
