32 – Monitoring T2S - ETH User Manual – v1.4
Graphical User Interface
• Passwords
Expert password: default
is pass456 but it’s strongly
recommended to change it.
Software update do not change
your password.
In case of lost password, please
refer to FAQ at page 65
• Network
In Connection mode, Select Hardware setup as
Standalone - System with T2S ETH or
With Catena - System with T2S ETH and display unit - Catena
Network address is configuration
of the T2S ETH
DHCP status: DHCP Disable
allows to configure static IP
to T2S ETH card.
When DHCP is enable IP
to T2S will be assigned
by the DHCP server or the
Router to which T2S ETH
is connected. To find the IP
address of T2S ETH card IP
Scanner tools can be used.
For more information refer
section 9.2, page 57.
IP address
Subnet mask
Default gateway
Primary DNS
Secondary DNS
DNS has to be configured where server has host name.
