SECTION 6 CESSNA
WEIGHT AND BALANCE/ MODEL T182T NAV III
EQUIPMENT LIST GFC 700 AFCS
U.S.
Figure 6-9 (Sheet 1 of 6)
ITEM NO EQUIPMENT LIST DESCRIPTION
REF
DRAWING
WT
LBS
ARM
INS.
11 - PAINT AND PLACARDS
11-01-S PAINT, OVERALL WHITE WITH COLOR STRIPE 0711117-1 19.6* 92.9*
- OVERALL WHITE COLOR 18.8 91.5
- COLOR STRIPING 0.8 135.9
21 - AIR CONDITIONING
21-01-S VENTILATORS, ADJUSTABLE, CABIN AIR 0719010 1.7 38.5
21-02-S CABIN HEATER SYSTEM, SHROUDED MUFFLER
TYPE
0750636 2.5 -29.5
21-03-R FORWARD AVIONICS COOLING FAN - MC24B3 3930370 0.5 12.7
21-04-R AFT AVIONICS COOLING FAN 3940389 1.1 125.5
22 - AUTO FLIGHT
22-01-S GFC 700 AFCS 6.9* 141.1*
- PITCH SERVO 3940452-1 2.3 185.9
- PITCH TRIM SERVO 3940454-1 2.3 176.4
- ROLL SERVO 3940453-1 2.3 61.0
23 - COMMUNICATIONS
23-01-S STATIC DISCHARGE WICKS, (SET OF 10) 1201131-2 0.3 152.9
23-02-R AUDIO/INTERCOM/MARKER BEACON 3930368
- GMA 1347 AUDIO PANEL 3910317-2 2.6 16.5
- CI-102 MARKER BEACON ANTENNA 3960193-2 0.5 131.5
23-03-R NAV/COM/GPS #1 COMPUTER 3940389
- GIA 63W INTEGRATED AVIONICS UNIT 3910317-4 4.9 134.0
- CI 2580-200 VHF COMM/GPS ANTENNA 3960222-7 0.5 61.2
23-04-S NAV/COM/GPS #2 COMPUTER 3940389
- GIA 63W INTEGRATED AVIONICS UNIT 3910317-4 4.9 134.0
- CI 2580-410 VHF COMM/GPS/XM ANTENNA 3960222-8 0.5 61.2
or
- CI 2580-200 VHF COMM/GPS ANTENNA 3960222-9 0.5 61.2
- CI 420-10 XM ANTENNA 3960234-1 0.5 41.5
24 - ELECTRICAL POWER
24-01-R ALTERNATOR, 28 VOLT, 95 AMP, -9910592-3 0750636 15.7 -33.4
24-02-R BATTERY, 24 VOLT, 10.00 AMP HOUR 0718016 27.2 132.1
24-03-R POWER DISTRIBUTION MODULE S3100-366 6.4* -2.5*
- ALTERNATOR CONTROL UNIT AC2101 0.2 -2.5
- MASTER CONTACTOR X61-0007 0.7 -2.5
- STARTER CONTACTOR X61-0027 0.7 -2.5
- AMMETER TRANSDUCER CS3200 0.1 -2.0
24-04-S BATTERY, STANDBY - AVT 200413,
24 VOLT, 6.20 AMP HOUR
0718023-1 14.0 10.8
T182TPHBUS-01
6-20
