CESSNA SECTION 2
MODEL T182T NAV III OPERATING LIMITATIONS
GFC 700 AFCS
U.S.
FAA APPROVED
POWERPLANT INSTRUMENT MARKINGS
Powerplant instrument markings and their color code significance are
shown in Figure 2-3. Operation with indications in the red range is
prohibited. Avoid operating with indicators in the yellow range.
POWERPLANT INSTRUMENT MARKINGS
INSTRUMENT
RED LINE
(MIN)
RED
ARC
(LWR)
YELLOW
ARC
GREEN ARC
(NORMAL
OPERATING
RANGE)
RED
ARC
(UPR)
RED
LINE
(MAX)
Tachometer ---- ---- ---- 2000 to 2400
RPM
2400*
to 2700
RPM
---
Manifold
Pressure
SL - 15,000 Ft
15,000 -
20,000 Ft
--- --- ---
15 to 28 in.hg.
15 to 27 in.hg.
32* to 35
in.hg.
---
Cylinder Head
Temperature
---- ---- ---- 200 to 500°F ---- 500°F
Oil
Temperature
---- ---- ---- 100 to 245°F 245* to
250°F
---
Oil Pressure ---- 0 to 20
PSI
---- 50 to 90 PSI 115* to
120 PSI
---
Fuel Quantity 0 (2.5
Gallons
Unusable
Each
Tank)
---- 0 to 8
Gallons
8 to 35
Gallons
---- ---
Fuel Flow ---- ---- ---- 0 to 18 GPH
24 GPH
---- ---
Vacuum Gage ---- ---- ---- 4.5 to 5.5
in.hg.
---- ---
Turbine Inlet
Temperature
(T.I.T.) (°F)
--- --- --- 1350 to
1685°F
1685* to
1700°F
*Maximum operating limit is lower end of red arc.
Figure 2-3
T182TPHBUS-00 2-7
