CESSNA SECTION 7
MODEL T182T NAV III AIRPLANE AND SYSTEM DESCRIPTION
GFC 700 AFCS
U.S.
AVIONICS SUPPORT EQUIPMENT (Continued)
12V POWER OUTLET
A power converter, located on the cabin side of the firewall just forward
of the right instrument panel, reduces the airplane's 28 VDC power to
12 VDC. This converter provides up to 10 amps of power to operate
portable devices such as notebook computers and audio players. The
power output connector (POWER OUTLET 12V -10A) is located on the
center pedestal (Refer to Figure 7-2).
A second power outlet connector (POWER OUTLET 12V - 10A) is
located in the right sidewall by the aft passenger seat. A switch located
on the switch panel labeled CABIN PWR 12V controls the operation of
the power outlets.
• Charging of lithium batteries may cause the lithium
batteries to explode.
• Take care to observe the manufacturer's power
requirements prior to plugging any device into the 12 volt
cabin power system connector. This system is limited to
a maximum of 10 amps, or if equipped with two
connectors 10 amps total.
• Use caution with power/adapter cables in the cabin to
avoid entangling occupants or cabin furnishings and to
prevent damage to cables supplying live electric current.
• Disconnect power/adapter cables when not in use.
(Continued Next Page)
T182TPHBUS-01
7-93
