SECTION 7 CESSNA
AIRPLANE AND SYSTEM DESCRIPTION MODEL T182T NAV III
GFC 700 AFCS
U.S.
SEATS
The seating arrangement consists of two vertically adjusting crew seats
for the pilot and front seat passenger, and an infinitely adjustable split
aft bench seat for rear seat passengers.
Seats used for the pilot and front seat passenger are adjustable
forward and aft, and up and down. Additionally, the angle of the seat
back is infinitely adjustable.
Forward and aft adjustment is made using the handle located below the
center of the seat frame. To position the seat, lift the handle, slide the
seat into position, release the handle and check that the seat is locked
in place. To adjust the height of the seat, rotate the large crank under
the right corner of the seat until a comfortable height is obtained. To
adjust the seat back angle, pull up on the release button, located in
center front of seat, just under the seat bottom, position the seat back
to the desired angle, and release the button. When the seat is not
occupied, the seat back will automatically fold forward whenever the
release button is pulled up.
The rear passenger seat consists of a fixed, one piece seat bottom and
an infinitely adjustable split back. Seat back controls are located
beneath each seat bottom and provide adjustment for each seat back.
To adjust the seat back, raise the lever, position the seat back to the
desired angle, release the lever, and check that the seat back is
securely locked in place.
Headrests are installed on both the front and rear seats. To adjust the
headrest, apply enough pressure to it to raise or lower it to the desired
level.
T182TPHBUS-01
7-24
