Chamberlain CHSL400EVC User Manual

17
CHSL400EVC
Input Voltage VAC 220-240
Input frequency Hz 50/60
Motor Voltage VDC 24V
Standby consumption
(without accessories)
W 4.45
Rated Power W 110
Rated Load Nm 3.6
Cycles per hour 5
Max. cyles per day 20
Max. gate weight kg 400
Max. gate width m 4
Max. opening speed mm/s 160
Maximum Torque Nm 12
End Limit System Magnetic switch
Operating Radio Frequency
Sending Power
MHz
RX 433MHz (433.30MHz, 433.92MHz, 434.54MHz)
RX 868MHz (868.30MHz, 868.95MHz, 869.85MHz)
TX 865.125MHz, 865.829MHz, 866.587MHz
< 10 mW
Code Security+ 2.0
Max. nr of remotes 180
Max. nr. of keypads 4
Max. nr. of myQ devices 16
External accessory power 24VDC - max. 500mA
Flahing lamp connector 24VDC - max. 500mA
E-Lock /Magnetic lock conenctor 24VDC - max. 500mA
External relay 24VDC - max. 500mA
Safety edge 8,2 kOhm
Max. nr. of IRs 3
Max. nr. of external inputs 3
Battery back-up unit 2 x 12V, 2.2Ah batteries model 490EV
Ingress Protection Motor IP 44
Noise Level dB < 70 db(A)
Working temperature °C -20°C to +55°C
Weight (kit) Kg 12
Transmitter Frequency
TX4REV-F
868MHz (868.30MHz, 868.95MHz, 869.85MHz)
Sending power <10mW
Battery CR2032 3V
10. TECHNICAL DATA

Chamberlain CHSL400EVC Specifications

General

Brand	Chamberlain
Model	CHSL400EVC
Category	Gate Opener
Language	English
