4
CHSL400EVC
Unité moteur avec
panneau de commande
Clés de
déverrouillage (2x)
Télécommandes
(2x)
Manuel
d’installation
1
2
3
3
4
5
4
1. Unité moteur avec panneau de commande
2. Crémaillère
3. Boucles magnétiques
4. Cellules photoélectriques à infrarouge
5. Lampe clignotante
8, 13 mm 8, 13 mm
2. ÉLÉMENTS LIVRÉS
3. OUTILS NÉCESSAIRES
4. VUE D’ENSEMBLE DE L’AUTOMATISME DE PORTAIL
Cellules
photoélectrique
Crémaillère (12x33 cm)
