13
Not Possible
Gate hits driveway.
Possible
Special swivel arm and hinges are required.
Swivel Arm
3" heavy steel posts can be
U-bolted to mounting plate and
cemented in ground.
Power and control
wiring can be run in
separate conduits.
INSTALLATION
UPHILL DRIVEWAY INSTALLATION (OPTIONAL)
POST MOUNTING PLATE INSTALLATION (OPTIONAL)
