Chamberlain CSW200UL8 - How to Order Repair Parts; Repair Part Names and Numbers

45
OUR LARGE SERVICE ORGANIZATION SPANS AMERICA. INSTALLATION AND SERVICE INFORMATION
IS AS NEAR AS YOUR TELEPHONE. SIMPLY DIAL OUR TOLL FREE NUMBER:
1-800-528-2806
www.liftmaster.com
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION:
• PART NUMBER
• PART NAME
• MODEL NUMBER
Address orders to:
LIFTMASTER
Technical Support Group
6050 S. Country Club Road
Tucson, Arizona 85706
850LM - 24V Radio Receiver
G6518CSW - Heater
K45-50676 - Star Knob
K23-51142 - Reset Button Assembly
K82-PX06-05 - PC Board Screws
Q018 - 1/2 HP Electric Motor
Q019 - Control Board Non UL (Not Shown)
Q025 - Motor Pulley (ID5/8)
Q027 - Motor Capacitor
Q029 - Limit Switch (One)
Q044 - Chain No. 50
Q045 - Drive Belt 1/2 HP 4L190
Q046 - Gear Reducer Pulley
Q059 - Output Arm Solid
Q062 - Cludge Cover - Stainless Steel
Q084 - Emergency Key Release
Q118 - Key for Access Door
Q175 - Belt UL DM/1 HP
Q183 - Sprocket (B50-16)
Q212 - Gear Reducer 40-30:1
Q216 - Output Shaft for 70 Reducer
K73-36687 - CSW200UL8™ Chassis for 70 Reducer
K75-35400-2 - Cover - HD Polyethylene
K75-36763 - Cover - DM HD Polyethylene
Q268 - Cludge Cover - Plastic
K75-36768 - Stainless Steel Cover
Q400E-1 - Omni Main PCB (OmniControl™)
Q401 - Omni 1 Horsepower Board
Q404 - Omni Alarm
Q407 - Omni Motor Harness 1HP
K10-36700 - Junction Box with On/Off Switch and Receptacle
K13-34729 - Dust Guard
Q410 - Surge Suppressor Terminal Block
Q520 - Omni Motor Harness
Q521 - Omni Motor Harness DM
Assembly Parts Number
NOTE:
Electronic Box Assembly - K75-34709-4
- Electronic Metal Box
- Surge Suppressor
- Dust Guard
Power Back-Up Unit - ODC2000CSW
- Drive Belt DC CSW (DM) Q042
- Back-Up Motor DC 12V
- Chassis DC Back-Up
- Hardware Kit for DC Back-Up
- Drive Belt DC CW 4L240 Q163
- Wire Harness DC-2000
- Pulley DC1000 1/2 ID
Assembly, limit Rack, CSW - Q165
- Limit Switch Bracket
- Limit Cam (Plastic Part)
Gear Box Assembly (Size 70) - Q210
- Sprocket
Sprocket and Chain Kit - Q057
- 1-1/8 inch dia. sprocket fits size 70 gear box
- 1 inch dia. sprocket fits size 60 gear box
- Sprocket #35
- Chain #35-72 Iinks
- Chain #35-68 Iinks
Cludge Assembly - Q061
- Arm Release Handle
- Output Shaft Cludge
REPAIR PARTS
HOW TO ORDER REPAIR PARTS
REPAIR PART NAMES AND NUMBERS
