Card Reader
External 120 Vac “Exit” Loop Detector
12 Vdc Failsafe Photoelectric Sensor
External 120 Vac "Safety" Loop Detector
Second Operator Link
Push Button
Telephone Entry System
Fire or any Key Switch
NOTE: Terminals 11 and 12 are the ONLY terminals that will
Open and Close with a single push of a button. All other
terminals will ONLY Open with a single push of a button.
Output Power
Ground
24 Vdc
Remote NOT Included
315 MHz Factory Installed
Radio Receiver
Dry Contact
Dry Contact
Separate power
for card reader.
Separate Power
Separate Power
Separate power
for TES.
120 Vac
Power
Removable
Terminals
Primary/Secondary
Connection
To ENSURE proper operation of external devices:
• ENSURE bare wires make good contact inside
removable terminal connections.
• DO NOT let wire insulation interfere with
connection.
OR
SURGE SUPPRESSOR TERMINAL CONNECTIONS
