Chamberlain ELITE Series User Manual

18
Setting RESIDENTIAL COMMERCIAL/
GENERAL ACCESS
COMMERCIAL INDUSTRIAL
Quick Close switch
setting
Normally set to OFF.
Normal gate close (timer or
control).
Normally set to OFF. Normal
gate close (timer or control).
Normally set to OFF. Normal
gate close (timer or control).
Set to ON, so that gate
closes immediately after
vehicle passes CLOSE EYES/
Interrupt loop.
Anti-Tail switch setting
Normally set to OFF. CLOSE
EYES/Interrupt loop
reverses a closing gate.
Normally set to OFF. CLOSE
EYES/Interrupt loop reverses a
closing gate.
Set to ON. In attempt to
prevent vehicle tail-gating,
CLOSE EYES/Interrupt loop
pauses a closing gate.
Set to ON. In attempt to
prevent vehicle tail-gating,
CLOSE EYES/Interrupt loop
pauses a closing gate.
Bipart Delay switch
setting
For DUAL-GATE site, set to
ON for gate that delays
upon opening.
For DUAL-GATE site, set to ON
for gate that delays upon
opening.
For DUAL-GATE site, set to
ON for gate that delays upon
opening.
For DUAL-GATE site, set to
ON for gate that delays upon
opening.
Aux Relay Out – Open
Limit Switch
Typically not required. Use with SAMS (Sequence
Access Management System).
1) Use with SAMS (Sequence
Access Management
System).
2) Connect “Gate Open”
indicator (e.g. light).
1) Use with SAMS (Sequence
Access Management
System).
2) Connect “Gate Open”
indicator (e.g. light).
Aux Relay Out – Close
Limit Switch
Typically not required. Typically not required. Connect “Gate Close/Secure”
indicator (e.g. light).
Connect “Gate Close/Secure”
indicator (e.g. light).
Aux Relay Out – Gate
Motion
Attach alert signal (audible
or visual alert system).
Attach alert signal (audible or
visual alert system).
Attach alert signal (audible or
visual alert system).
Attach alert signal (audible or
visual alert system).
Aux Relay Out –
Pre-Motion Delay
Attach alert signal (audible
or visual alert system).
Attach alert signal (audible or
visual alert system).
Attach alert signal (audible or
visual alert system).
Attach alert signal (audible or
visual alert system).
Aux Relay Out – Power
Attach visual alert to know
when system is charging
batteries (i.e. not running
on batteries).
Attach visual alert to know when
system is charging batteries (i.e.
not running on batteries).
Attach visual alert to know
when system is charging
batteries (i.e. not running on
batteries).
Attach visual alert to know
when system is charging
batteries (i.e. not running on
batteries).
Aux Relay Out – Tamper
(Slide Gates Only)
Attach alert signal (audible
or visual alert system) to
indicate if gate is manually
tampered with by being
pushed off of close limit.
Attach alert signal (audible or
visual alert system) to indicate if
gate is manually tampered with
by being pushed off of close
limit.
Attach alert signal (audible or
visual alert system) to
indicate if gate is manually
tampered with by being
pushed off of close limit.
Attach alert signal (audible or
visual alert system) to
indicate if gate is manually
tampered with by being
pushed off of close limit.
Cycle Quantity Feedback
Use during servicing only to
determine operator cycles.
Use during servicing only to
determine operator cycles.
Use during servicing only to
determine operator cycles.
Use during servicing only to
determine operator cycles.
Fire Dept Open input
Typically not required. Connect emergency access
system (Knox box switch, SOS
system, etc.).
Typically not required. Typically not required.
Heater Accessory
(Model HTR)
Suggested use if outside
temperature remains below
0°F (-18°C).
Suggested use if outside
temperature remains below
0°F (-18°C).
Suggested use if outside
temperature remains below
0°F (-18°C).
Suggested use if outside
temperature remains below
0°F (-18°C).
SETTINGS
GATE OPERATOR SETUP EXAMPLES
The following are example setups for the gate operator. Your specific site requirements may be different. Always setup the operator system to the site
requirements, including all necessary entrapment protection devices.
RESIDENTIAL: One to four residential homes sharing a gated entrance/exit, allowing vehicle access trumps security concerns
COMMERCIAL/GENERAL ACCESS: A residential community (more than four homes) having one or more gated entrances/exits, allowing
vehicle access trumps security concerns
COMMERCIAL: Business site where security (gate closed) is important
INDUSTRIAL: Large business site where security is required
